Technical details
Compliance certificates: RoHS, CE, CB
Design
Screen shape: Flat
Product design: Digital signage flat panel
Product colour: Black
Orientation: Horizontal/Vertical
VESA mounting: Yes
Panel mounting interface: 200 x 200 mm
Placement supported: Indoor
Mounting type: Wall
Power
AC input frequency: 50 - 60 Hz
AC input voltage: 100 - 240 V
Energy efficiency scale: A to G
Energy efficiency class (SDR): G
Energy consumption (SDR) per 1000 hours: 56 kWh
Power consumption (standby): 0.5 W
Operational conditions
Operating relative humidity (H-H): 20 - 80%
Storage temperature (T-T): -20 - 60 °C
Storage relative humidity (H-H): 5 - 95%
Operating temperature (T-T): 0 - 40 °C
Weight & dimensions
Display depth: 63.5 mm
Display width: 973 mm
Display weight: 10.7 kg
Display height: 561.2 mm
Network
Wi-Fi standards: Wi-Fi 6 (802.11ax)
Ethernet LAN: Yes
Wi-Fi: Yes
Performance
Operating hours (hours/days): 24/7
On Screen Display (OSD) languages: Simplified Chinese, Danish, Finnish, Spanish, Russian, Swedish, Turkish, German, Italian, Dutch, Japanese, Polish, English, Norwegian, Traditional Chinese, French, Arabic, Portuguese
Number of OSD languages: 18
Purpose: Universal
On Screen Display (OSD): Yes
Mean time between failures (MTBF): 50000 h
Packaging content
Cables included: AC, RS-232, IR sensor
Wi-Fi module included: Yes
Batteries included: Yes
Remote control included: Yes
Display
Response time: 8 ms
Viewing angle, horizontal: 178°
Display diagonal: 108 cm (42.5")
Viewing angle, vertical: 178°
HD type: 4K Ultra HD
Pixel pitch: 0.2451 x 2451 mm
Display resolution: 3840 x 2160 pixels
Display number of colours: 1.07 billion colours
Contrast ratio (dynamic): 500000:1
Native aspect ratio: 16:9
Haze rate: 25%
Display brightness: 600 cd/m²
Contrast ratio (typical): 1200:1
Touchscreen: No
Display diagonal (metric): 108 cm
Panel type: ADS
Native refresh rate: 60 Hz
Display technology: LCD
Audio
Number of built-in speakers: 2
Built-in speaker(s): Yes
RMS rated power: 20 W
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
DisplayPorts quantity: 1
DisplayPort version: 1.4
USB connector type: Micro-USB, USB Type-C, USB Type-A
Infrared data port: Yes
HDMI input ports quantity: 2
DisplayPorts in: 1
RS-232C: Yes
HDMI output ports quantity: 1
USB ports quantity: 4
USB port: Yes
DVI port: No
HDMI ports quantity: 3
HDMI version: 2.0
Other features
Bluetooth: Yes
Bluetooth version: 5.2
Computer system
Processor cores: 8
Processor model: Rockchip RK3576
On-board graphics card model: Mali-G52 MC3
Internal memory: 4 GB
Processor family: ARM Rockchip
Processor architecture: ARM Cortex-A53+Cortex-A72
Operating system installed: Android 14
Video formats supported: H.264, H.265, MPEG4, VP9, AVI, WEBM, MPEG, MP4, H.263, VP8
Computer system type: System on Chip (SoC)
Computer system: Yes
Internal storage capacity: 32 GB
Built-in processor: Yes
Audio formats supported: HE-AAC, MPEG, AAC
Image formats supported: JPEG, BMP, PNG
Processor manufacturer: Rockchip
