Technical details
Compliance certificates: RoHS, CE, CB
Design
Bezel width (bottom): 1.49 cm
Bezel width (top): 1.49 cm
Bezel width (side): 1.49 cm
VESA mounting: Yes
Panel mounting interface: 100 x 100 mm, 200 x 200 mm
Product colour: Black
Power
Energy efficiency class (SDR): F
AC input voltage: 100 - 240 V
AC input frequency: 50/60 Hz
Operational conditions
Storage temperature (T-T): -20 - 60 °C
Operating temperature (T-T): 0 - 40 °C
Storage relative humidity (H-H): 5 - 95%
Operating relative humidity (H-H): 20 - 80%
Weight & dimensions
Display height: 837.3 mm
Display weight: 29 kg
Display width: 1462.3 mm
Network
Ethernet LAN: Yes
Wi-Fi: Yes
Performance
On Screen Display (OSD) languages: Turkish, Arabic, Portuguese, Traditional Chinese, French, Swedish, German, Italian, Dutch, Russian, Finnish, Simplified Chinese, Danish, Japanese, English, Norwegian, Spanish, Polish
Number of OSD languages: 18
Mean time between failures (MTBF): 50000 h
On Screen Display (OSD): Yes
Packaging content
Cables included: IR sensor, RS-232, AC
Display
Panel type: VA
Display brightness: 600 cd/m²
Contrast ratio (typical): 1200:1
Display diagonal (metric): 125.7 cm
Display technology: LCD
Haze rate: 25%
Display resolution: 3840 x 2160 pixels
HD type: Full HD
Viewing angle, horizontal: 178°
Pixel pitch: 0.2854 x 0.2854 mm
Viewing angle, vertical: 178°
Display diagonal: 165.1 cm (65")
Display number of colours: 1.07 billion colours
Response time: 8 ms
Contrast ratio (dynamic): 500000:1
Native aspect ratio: 16:9
Audio
RMS rated power: 20 W
Number of built-in speakers: 2
Built-in speaker(s): Yes
Ports & interfaces
USB port: Yes
USB version: 2.0/3.2 Gen 2 (3.1 Gen 2)
USB ports quantity: 1
Remote (IR) output: 1
Number of antenna connectors: 1
Remote (IR) input: 1
RS-232C: Yes
Ethernet LAN (RJ-45) ports: 1
HDMI version: 2.0
DisplayPort version: 1.4
RS-232 interface: Yes
USB connector type: Micro-USB B, USB Type-C
HDMI ports quantity: 2
DisplayPorts quantity: 1
Computer system
Video formats supported: H.265, AVI, WEBM, H.264, MPEG, MP4, H.263, VP8, MPEG4
Computer system: Yes
Built-in processor: Yes
Image formats supported: JPEG, BMP, PNG
Audio formats supported: AAC, HEAAC / MPEG
Computer system type: System on Chip (SoC)
Operating system version: 14
Internal storage capacity: 32 GB
Processor model: A53
Operating system installed: Android
Internal memory: 4 GB
On-board graphics card model: Mali-G52 MC3
Processor cores: 8
Processor manufacturer: ARM
