Technical details
Compliance certificates: CB, RoHS, CE
Design
VESA mounting: Yes
Panel mounting interface: 200 x 200 mm, 100 x 100 mm
Product colour: Black
Bezel width (side): 1.49 cm
Bezel width (bottom): 1.49 cm
Bezel width (top): 1.49 cm
Power
AC input frequency: 50/60 Hz
AC input voltage: 100 - 240 V
Energy efficiency class (SDR): F
Operational conditions
Operating relative humidity (H-H): 20 - 80%
Storage temperature (T-T): -20 - 60 °C
Storage relative humidity (H-H): 5 - 95%
Operating temperature (T-T): 0 - 40 °C
Weight & dimensions
Display width: 1683.5 mm
Display weight: 37 kg
Display height: 961.7 mm
Network
Ethernet LAN: Yes
Wi-Fi: Yes
Performance
On Screen Display (OSD): Yes
On Screen Display (OSD) languages: Japanese, Turkish, Finnish, Russian, Polish, German, Italian, Dutch, Arabic, Portuguese, Traditional Chinese, French, Spanish, Simplified Chinese, Danish, Swedish, English, Norwegian
Number of OSD languages: 18
Mean time between failures (MTBF): 50000 h
Packaging content
Cables included: IR sensor, RS-232, AC
Display
Display resolution: 3840 x 2160 pixels
Response time: 8 ms
Viewing angle, horizontal: 178°
Display number of colours: 1.07 billion colours
Pixel pitch: 0.2854 x 0.2854 mm
Display diagonal: 190.5 cm (75")
Viewing angle, vertical: 178°
HD type: Full HD
Contrast ratio (typical): 1200:1
Contrast ratio (dynamic): 500000:1
Display technology: LCD
Native aspect ratio: 16:9
Display brightness: 600 cd/m²
Display diagonal (metric): 125.7 cm
Haze rate: 25%
Panel type: VA
Audio
Built-in speaker(s): Yes
Number of built-in speakers: 2
RMS rated power: 20 W
Ports & interfaces
USB port: Yes
USB connector type: Micro-USB B, USB Type-C
DisplayPorts quantity: 1
Ethernet LAN (RJ-45) ports: 1
HDMI ports quantity: 2
RS-232 interface: Yes
HDMI version: 2.0
DisplayPort version: 1.4
USB version: 2.0/3.2 Gen 2 (3.1 Gen 2)
Remote (IR) output: 1
RS-232C: Yes
Number of antenna connectors: 1
USB ports quantity: 1
Remote (IR) input: 1
Computer system
Operating system installed: Android
Video formats supported: H.265, H.264, AVI, WEBM, VP8, MPEG4, MPEG, MP4, H.263
Built-in processor: Yes
Internal memory: 4 GB
Audio formats supported: AAC, HEAAC / MPEG
On-board graphics card model: Mali-G52 MC3
Processor cores: 8
Processor model: A53
Image formats supported: BMP, PNG, JPEG
Processor manufacturer: ARM
Operating system version: 14
Computer system: Yes
Internal storage capacity: 32 GB
Computer system type: System on Chip (SoC)
