Technical details
Compliance certificates: VCCI, EMF, PSB, CE, Federal Communications Commission (FCC), ETL, BSMI, CB, EAC
Design
Mounting type: Wall
Product design: Digital signage flat panel
Screen shape: Flat
Product colour: Black
Panel mounting interface: 400 x 400
Placement supported: Indoor
VESA mounting: Yes
Orientation: Horizontal/Vertical
Power
Power consumption (max): 171 W
AC input frequency: 50 - 60 Hz
AC input voltage: 100 - 240 V
Power consumption (standby): 0.5 W
Power consumption (typical): 104 W
Energy efficiency class (SDR): G
Energy consumption (SDR) per 1000 hours: 102 kWh
Energy efficiency scale: A to G
Operational conditions
Storage temperature (T-T): -20 - 60 °C
Operating relative humidity (H-H): 20 - 80%
Operating temperature (T-T): 0 - 40 °C
Storage relative humidity (H-H): 5 - 95%
Weight & dimensions
Display weight: 17.4 kg
Display depth: 76.8 mm
Display width: 1128.4 mm
Display height: 649 mm
Network
Ethernet LAN: Yes
Wi-Fi: No
Performance
On Screen Display (OSD): Yes
Purpose: Universal
International Protection (IP) code: IP5X
On Screen Display (OSD) languages: Simplified Chinese, Traditional Chinese, German, Swedish, Japanese, Danish, Italian, Dutch, English, Norwegian, Russian, Finnish, Polish, Turkish, Spanish, Arabic, Portuguese, French
Number of OSD languages: 18
Operating hours (hours/days): 24/7
Mean time between failures (MTBF): 50000 h
Packaging content
Cables included: RS-232, AC
Batteries included: Yes
Remote control included: Yes
Display
Display diagonal: 125.7 cm (49.5")
Display diagonal (metric): 125.7 cm
Response time: 8 ms
Display resolution: 3840 x 2160 pixels
Viewing angle, horizontal: 178°
Panel type: VA
Touchscreen: No
HD type: 4K Ultra HD
Viewing angle, vertical: 178°
Contrast ratio (dynamic): 500000:1
Contrast ratio (typical): 4000:1
Native aspect ratio: 16:9
Pixel pitch: 0.2854 x 0.2854 mm
Display technology: LCD
Display number of colours: 1.07 billion colours
Native refresh rate: 60 Hz
Display brightness: 800 cd/m²
Haze rate: 25%
Audio
Built-in speaker(s): Yes
RMS rated power: 20 W
Number of built-in speakers: 2
Ports & interfaces
HDMI ports quantity: 4
DisplayPorts quantity: 2
USB port: Yes
DVI-I ports quantity: 1
DVI port: Yes
Ethernet LAN (RJ-45) ports: 1
HDMI version: 2.0
USB version: 2.0
DisplayPort version: 1.2
USB ports quantity: 2
HDMI output ports quantity: 1
Infrared data port: Yes
DisplayPorts in: 1
RS-232C: Yes
OPS module slot: Yes
HDMI input ports quantity: 3
DisplayPorts out: 1
Sensors
Ambient light sensor: Yes
Computer system
Operating system installed: Android 14
Video formats supported: MPEG2, H.264, M-JPEG, MPEG1, H.265, WMV3
Internal memory: 8 GB
Audio formats supported: MPEG, HE-AAC, AAC
Image formats supported: JPEG, BMP, PNG
Built-in processor: Yes
Computer system type: System on Chip (SoC)
Computer system: Yes
Internal storage capacity: 64 GB
