Design
Market positioning: Gaming
Product colour: Grey
Power
Power consumption (typical): 17.8 W
Energy consumption (SDR) per 1000 hours: 14 kWh
Energy consumption (HDR) per 1000 hours: 22 kWh
Energy efficiency class (SDR): D
Power consumption (standby): 0.5 W
Power supply type: Internal
Energy efficiency class (HDR): F
AC input frequency: 50/60 Hz
AC input voltage: 100 - 240 V
Power consumption (off): 0.3 W
Operational conditions
Non-operating altitude: 0 - 12192 m
Operating relative humidity (H-H): 20 - 80%
Storage temperature (T-T): -20 - 60 °C
Operating temperature (T-T): 0 - 40 °C
Operating altitude: 0 - 3658 m
Weight & dimensions
Width (without stand): 544 mm
Weight (with stand): 3.04 kg
Weight (without stand): 2.5 kg
Depth (without stand): 50 mm
Height (without stand): 321 mm
Depth (with stand): 216 mm
Height (with stand): 433 mm
Width (with stand): 544 mm
Performance
VESA Adaptive Sync support: Yes
Flicker-free technology: Yes
Component video sync: Separate sync
Low Blue Light technology: Yes
AMD FreeSync: No
NVIDIA G-SYNC: No
Packaging data
Package width: 690 mm
Package weight: 5.36 kg
Package depth: 124 mm
Package height: 420 mm
Bundled software: Evnia Precision Centre
Packaging content
Stand included: Yes
Cables included: HDMI, Power
Manual: Yes
Display
Response time measurement type: GTG (Gray to Gray)
Colour gamut standard: sRGB
DCI-P3 coverage: 93%
High Dynamic Range (HDR) technology: High Dynamic Range 10 (HDR10)
Haze rate: 25%
Surface hardness: 3H
Dynamic contrast ratio marketing name: Mega Infinity DCR
Backlight type: W-LED
Touchscreen: No
sRGB coverage (typical): 120%
Viewable size, vertical: 29.6 cm
Display sRGB: Yes
Display technology: LCD
Contrast ratio (typical): 1500:1
Panel type: IPS
DDC/CI: Yes
Viewable size, horizontal: 52.7 cm
Anti-glare screen: Yes
Adobe RGB coverage: 89%
SmartResponse: 0.5 ms
Display diagonal (metric): 60.5 cm
NTSC coverage (typical): 110%
High Dynamic Range (HDR) supported: Yes
Pixel density: 93 ppi
Maximum refresh rate: 144 Hz
Horizontal scan range: 30 - 160 kHz
Display diagonal: 60.5 cm (23.8")
Display resolution: 1920 x 1080 pixels
Screen shape: Flat
Vertical scan range: 48 - 144 Hz
Viewing angle, horizontal: 178°
Native aspect ratio: 16:9
LED backlight: Yes
Response time: 4 ms
Display brightness (typical): 300 cd/m²
Viewing angle, vertical: 178°
HD type: Full HD
Display number of colours: 16.7 million colours
Pixel pitch: 0.2745 x 0.2745 mm
Multimedia
Built-in speaker(s): No
Built-in camera: No
Ergonomics
Plug and Play: Yes
Panel mounting interface: 100 x 100 mm
On Screen Display (OSD) languages: Spanish, Russian, Czech, Greek, Ukrainian, Finnish, Traditional Chinese, French, Korean, Swedish, Hungarian, German, Italian, Dutch, Turkish, English, Japanese, Simplified Chinese, Polish, Portuguese
Number of OSD languages: 21
Tilt adjustment: Yes
VESA mounting: Yes
Height adjustment: No
On Screen Display (OSD): Yes
LED indicators: Operation, Stand-by
Cable lock slot type: Kensington
Tilt angle range: -5 - 20°
Cable lock slot: Yes
Ports & interfaces
HDMI ports quantity: 1
HDCP version: 1.4
HDMI: Yes
Built-in USB hub: No
HDMI version: 1.4
Headphone out: Yes
DisplayPort version: 1.4
DisplayPorts quantity: 1
HDCP: Yes
Other features
Compliance certificates: RoHS
Regulatory Approvals: CEL, CCC, CECP
Recyclable packaging material: 100%
Brand specific technologies: Crosshair
EasyRead mode: Yes
Picture enhancement: SmartImage game
Mean time between failures (MTBF): 50000 h
Shadow control: Yes
Adaptive synchronisation: Yes
LowBlue mode: Yes
Exterior finish type: Textured
Recycling data
Post-consumer recycled plastic: 85%
