Technical details
Warranty period: 3 year(s)
Regulatory Approvals: CE, CB, UL, FCC
Design
Product colour: Black
Orientation: Horizontal/Vertical
Panel mounting interface: 100 x 100 mm
Bezel width (side): 1.86 cm
Bezel width (top): 1.86 cm
Product design: Digital signage flat panel
Bezel width (bottom): 2.2 cm
VESA mounting: Yes
Placement supported: Indoor
Power
Input voltage: 20 V
Operational conditions
Operating relative humidity (H-H): 20 - 80%
Operating altitude: 0 - 3000 m
Operating temperature (T-T): 15 - 35 °C
Storage temperature (T-T): -20 - 60 °C
Weight & dimensions
Display width: 598.6 mm
Display weight: 2.7 kg
Display height: 350.2 mm
Display depth: 37.5 mm
Network
Ethernet LAN data rates: 100, 10
Wi-Fi standards: 802.11g, Wi-Fi 4 (802.11n), 802.11b, 802.11a, Wi-Fi 5 (802.11ac)
Ethernet LAN: Yes
Wi-Fi: Yes
Performance
Purpose: Commercial
On Screen Display (OSD): Yes
On Screen Display (OSD) languages: English, Simplified Chinese
Number of OSD languages: 2
Display
Display diagonal: 64.3 cm (25.3")
Display resolution: 3200 x 1800 pixels
Display number of colours: 60000 colours
Native aspect ratio: 16:9
Ports & interfaces
Audio (L/R) out: 1
USB port: Yes
Card reader integrated: Yes
Compatible memory cards: MicroSD (TransFlash)
Other features
Bluetooth: Yes
Quick start guide: Yes
Bluetooth version: 5.1
Computer system
Internal memory: 2 GB
Internal storage capacity: 16 GB
Processor manufacturer: Rockchip
Processor family: ARM Rockchip
Operating system installed: Android 11
Processor model: PX30S
Built-in processor: Yes
