Certification: FCC Class A, CE Class A
Design
Product colour: Black
Internal: No
DIN rail mounting: Yes
LED indicators: Yes
Power
Input voltage: 5 V
Power consumption (typical): 5.6 W
Input current: 2 A
Operational conditions
Storage temperature (T-T): -10 - 70 °C
Operating temperature (T-T): 0 - 50 °C
Operating relative humidity (H-H): 5 - 95%
Storage relative humidity (H-H): 5 - 95%
Weight & dimensions
Weight: 200 g
Height: 26 mm
Depth: 70 mm
Width: 94 mm
Network
Ethernet LAN data rates: 1000, 100 Mbit/s, 10
Maximum data transfer rate: 1000 Mbit/s
Networking standards: IEEE 802.3u, IEEE 802.3, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3z
Duplex system: Full, Half
Converter input interface: 10Base-T, 1000Base-T, 100Base-T
Auto MDI/MDI-X: Yes
Ethernet interface type: Gigabit Ethernet
Converter output interface: 1000Base-SX, 1000Base-LX
Performance
Fiber cable diameters supported (core/cladding): 50/125, 62.5/125 µm, 9/125 µm
Maximum transfer distance: 100 m
Fiber mode structure: Multi-mode
Ports & interfaces
Connectivity technology: Wired
Ethernet LAN (RJ-45) ports: 2
Fiber optic connector: SFP
Logistics data
Harmonized System (HS) code: 85176990
