Design
Stackable: No
Wall mountable: Yes
International Protection (IP) code: IP30
LED indicators: Power, Activity, Link
DIN rail mounting: Yes
Housing material: Metal
Rack mounting: No
Product colour: Blue
Power
Power protection features: Reverse polarity
Power consumption (typical): 8.7 W
DC input voltage: 24 V
Input voltage: 12 - 48 V
Redundant power supply (RPS) support: Yes
Operational conditions
Operating relative humidity (H-H): 5 - 95%
Heat dissipation: 29.69 BTU/h
Operating temperature (T-T): -40 - 75 °C
Storage relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -40 - 75 °C
Management features
Switch type: Unmanaged
Weight & dimensions
Depth: 87 mm
Height: 135 mm
Width: 56 mm
Weight: 540 g
Network
Full duplex: Yes
Copper ethernet cabling technology: 100BASE-TX, 10BASE-T, 1000BASE-T
Cable types supported: Cat5, Cat5e, Cat6
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Auto MDI/MDI-X: Yes
Auto-negotiation: Yes
10G support: No
Flow control support: Yes
Ports & interfaces
Fiber optic connector: SFP
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity: 8
SFP module slots quantity: 2
Other features
Terminal block port: Yes
Logistics data
Harmonized System (HS) code: 85176990
Data transmission
Jumbo frames: 9216
Jumbo frames support: Yes
Switching capacity: 20 Gbit/s
Store-and-forward: Yes
Throughput: 14.88 Mpps
MAC address table: 4000 entries
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Optical fiber
Fiber ethernet cabling technology: 100BASE-FX
Transmission distance (max): 60 km
