Design
Wall mountable: Yes
International Protection (IP) code: IP30
LED indicators: Yes
Housing material: Metal
Product colour: Blue
DIN rail mounting: Yes
Reset button: Yes
Power
Power consumption (max): 15 W
DC input voltage: 12 - 48 V
Security
Access Control List (ACL): Yes
Static port security: Yes
Security algorithms: SSL/TLS, SSH-2, SSH, SNMPv3
MAC address filtering: Yes
IGMP snooping: Yes
IP-MAC-Port binding: Yes
DHCP features: DHCP relay
Authentication: Port-based authentication
BPDU filtering/protection: Yes
Operational conditions
Heat dissipation: 51.2 BTU/h
Operating temperature (T-T): -40 - 75 °C
Storage temperature (T-T): -40 - 85 °C
Operating relative humidity (H-H): 5 - 95%
Management features
ARP inspection: Yes
Switch type: Managed
Web-based management: Yes
Quality of Service (QoS) support: Yes
Switch layer: L2/L4
Weight & dimensions
Weight: 813 g
Height: 152 mm
Width: 66 mm
Depth: 107 mm
Network
Full duplex: Yes
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1Q, IEEE 802.3x, IEEE 802.1D, IEEE 802.3z, IEEE 802.1ab, IEEE 802.1w, IEEE 802.1x, IEEE 802.3az, IEEE 802.3ad, IEEE 802.1s, IEEE 802.3u
VLAN support: Yes
10G support: No
Number of VLANs: 4094
Virtual LAN features: Stacked VLAN, Voice VLAN, Tagged VLAN, Private VLAN
Auto MDI/MDI-X: Yes
Half duplex: Yes
Port mirroring: Yes
Link aggregation: Yes
Spanning tree protocol: Yes
Performance
Firmware upgradeable: Yes
Protocols
GARP VLAN Registration Protocol (GVRP): Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity: 16
Console port: RJ-45
SFP module slots quantity: 2
Data transmission
Switching capacity: 36 Gbit/s
Jumbo frames support: Yes
MAC address table: 8000 entries
Throughput: 26.79 Mpps
Packet buffer memory: 4.1 MB
Store-and-forward: Yes
Jumbo frames: 10000
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Multicast features
Multicast support: Yes
