Design
Product colour: Blue, White
LED indicators: Activity, System, Link, PoE, Power
Housing material: Aluminium
Safety: IEC 60068-2-32, IEC 60068-2-27, IEC 60068-2-6
Reset button: Yes
Stackable: No
DIN rail mounting: Yes
Wall mountable: Yes
International Protection (IP) code: IP30
Rack mounting: No
Power
Power consumption (max): 152.96 W
Input current: 3.5 A
DC input voltage: 48 - 56 V
Power consumption (typical): 5.04 W
Security
Security algorithms: SNMP, 128-bit SSL, SSH, 802.1x RADIUS
MAC address filtering: Yes
IGMP snooping: Yes
IP-MAC-Port binding: Yes
Access Control List (ACL): Yes
DHCP features: DHCP client
BPDU filtering/protection: Yes
SSH/SSL support: Yes
Authentication: Port-based authentication
Static port security: Yes
Operational conditions
Storage relative humidity (H-H): 5 - 95%
Operating relative humidity (H-H): 5 - 95%
Heat dissipation: 523.8 BTU/h
Operating temperature (T-T): -40 - 75 °C
Storage temperature (T-T): -40 - 85 °C
Management features
Web-based management: Yes
Switch layer: L2/L4
System event log: Yes
MIB support: RFC 1215, RFC 1493, RFC 2674, RFC 2737, RFC 2819, RFC 2863, RFC 3635
Traffic classification: Yes
Quality of Service (QoS) support: Yes
ARP inspection: Yes
Switch type: Managed
Weight & dimensions
Depth: 107.3 mm
Weight: 1 kg
Width: 76.8 mm
Height: 152 mm
Network
Networking standards: IEEE 802.1D, IEEE 802.3z, IEEE 802.3ad, IEEE 802.1s, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1w, IEEE 802.1ab, IEEE 802.1Q, IEEE 802.3x, IEEE 802.1x, IEEE 802.3u
Link aggregation: Yes
Rate limiting: Yes
Number of VLANs: 256
Virtual LAN features: Private VLAN, Stacked VLAN, Protocol-based VLAN
Broadcast storm control: Yes
Port mirroring: Yes
Copper ethernet cabling technology: 10BASE-T, 100BASE-FX, 1000BASE-SX, 100BASE-TX, 1000BASE-LX
10G support: No
VLAN support: Yes
Auto MDI/MDI-X: Yes
Spanning tree protocol: Yes
Flow control support: Yes
Performance
Firmware upgradeable: Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 8
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
SFP module slots quantity: 2
Other features
Terminal block port: Yes
Logistics data
Harmonized System (HS) code: 85176990
Data transmission
Jumbo frames support: Yes
Packet buffer memory: 4.1 MB
MAC address table: 8000 entries
Number of trunks: 4
Switching capacity: 20 Gbit/s
Jumbo frames: 10000
Throughput: 14.8 Mpps
Store-and-forward: Yes
Power over Ethernet (PoE)
Total Power over Ethernet (PoE) budget: 144 W
Power over Ethernet (PoE) ports quantity: 4
Power over Ethernet (PoE): Yes
Power over Ethernet (PoE) voltage range: 48 - 56 V
Multicast features
Multicast support: Yes
Number of multicast groups filtered: 256
Optical fiber
Fiber ethernet cabling technology: 100BASE-FX, 1000BASE‑LX, 1000BASE‑BX, 1000BASE‑SX
