Design
International Protection (IP) code: IP30
Wall mountable: Yes
DIN rail mounting: Yes
Housing material: Metal
LED indicators: Yes
Product colour: Blue
Power
Redundant power supply (RPS) support: Yes
Power consumption (typical): 3.6 W
DC input voltage: 24 V
Operational conditions
Heat dissipation: 12.35 BTU/h
Operating relative humidity (H-H): 5 - 90%
Storage relative humidity (H-H): 5 - 90%
Storage temperature (T-T): -40 - 75 °C
Operating temperature (T-T): -40 - 75 °C
Management features
Switch type: Unmanaged
Weight & dimensions
Height: 104 mm
Width: 30 mm
Depth: 70 mm
Weight: 252 g
Network
Cable types supported: Cat5, Cat5e, Cat3, Cat4, Cat6
Full duplex: Yes
Auto-negotiation: Yes
Flow control support: Yes
MAC address auto-aging supported: Yes
10G support: No
Auto MDI/MDI-X: Yes
MAC address auto-learning supported: Yes
Networking standards: IEEE 802.3az, IEEE 802.3x, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3u
Ports & interfaces
Gigabit Ethernet (copper) ports quantity: 5
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity: 5
Logistics data
Harmonized System (HS) code: 85176990
Data transmission
Jumbo frames: 9000
Store-and-forward: Yes
Jumbo frames support: Yes
Switching capacity: 10 Gbit/s
MAC address table: 4000 entries
Packet buffer memory: 1 MB
Throughput: 7.4 Mpps
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
