Design
International Protection (IP) code: IP30
Wall mountable: Yes
Reset button: Yes
LED indicators: Yes
DIN rail mounting: Yes
Housing material: Metal
Product colour: Blue
Power
Power consumption (max): 8.5 W
Redundant power supply (RPS) support: Yes
DC input voltage: 24 V
Security
Access Control List (ACL): Yes
IGMP snooping: Yes
BPDU filtering/protection: Yes
Security algorithms: SSH, SSL/TLS, SNMPv3
IP-MAC-Port binding: Yes
SSH/SSL support: Yes
Authentication: MAC-based authentication, Port-based authentication
Operational conditions
Operating temperature (T-T): -40 - 75 °C
Heat dissipation: 29.2 BTU/h
Operating relative humidity (H-H): 5 - 95%
Storage relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -40 - 85 °C
Management features
Switch layer: L2+
Traffic classification: Yes
Switch type: Managed
Web-based management: Yes
Quality of Service (QoS) support: Yes
Weight & dimensions
Height: 135 mm
Width: 32 mm
Weight: 456 g
Depth: 87 mm
Network
MAC address auto-aging supported: Yes
Rate limiting: Yes
Link aggregation: Yes
Virtual LAN features: Tagged VLAN, Private VLAN, Protocol-based VLAN
Networking standards: IEEE 802.3ah, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1x, IEEE 802.1ag, IEEE 802.1Q, IEEE 802.3x, IEEE 802.3ad, IEEE 802.1s, IEEE 802.1ab, IEEE 802.3u, IEEE 802.1w, IEEE 802.1D, IEEE 802.3z, IEEE 802.1ad, IEEE 1588v2
Full duplex: Yes
Copper ethernet cabling technology: 10BASE-T, 100BASE-T, 1000BASE-T
Broadcast storm control: Yes
VLAN support: Yes
Spanning tree protocol: Yes
Auto MDI/MDI-X: Yes
Port mirroring: Yes
MAC address auto-learning supported: Yes
10G support: No
Flow control support: Yes
Number of VLANs: 4094
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 4
SFP module slots quantity: 2
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Console port: RJ-45
Gigabit Ethernet (copper) ports quantity: 4
Logistics data
Harmonized System (HS) code: 85176990
Data transmission
Throughput: 8.9 Mpps
Jumbo frames: 9000
Jumbo frames support: Yes
Number of queues: 8
Switching capacity: 12 Gbit/s
MAC address table: 8000 entries
Store-and-forward: Yes
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Multicast features
Multicast support: Yes
Safety warning
Warnings: Do not open the case or try to repair it yourself.
