Design
LED indicators: Yes
Housing material: Metal
International Protection (IP) code: IP30
Product colour: Blue
Wall mountable: Yes
Rack mounting: No
Stackable: No
DIN rail mounting: Yes
Power
Power consumption (typical): 7.5 W
Power supply included: No
DC input voltage: 12 - 48 V
Operational conditions
Operating temperature (T-T): -40 - 75 °C
Storage relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -40 - 75 °C
Operating relative humidity (H-H): 5 - 95%
Management features
Switch type: Unmanaged
Weight & dimensions
Depth: 87 mm
Height: 135 mm
Weight: 425 g
Width: 32 mm
Network
Networking standards: IEEE 802.3x, IEEE 802.3z, IEEE 802.3, IEEE 802.1p, IEEE 802.3u
Copper ethernet cabling technology: 1000BASE-T, 10BASE-T, 100BASE-T
Full duplex: Yes
Auto MDI/MDI-X: Yes
Auto-negotiation: Yes
Cable types supported: Cat6, Cat5, Cat5e
Half duplex: Yes
10G support: No
Flow control support: Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 4
SFP module slots quantity: 2
Fiber optic connector: SFP
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Logistics data
Harmonized System (HS) code: 85176990
Data transmission
Switching capacity: 18 Gbit/s
Jumbo frames support: Yes
Throughput: 13.39 Mpps
MAC address table: 4000 entries
Jumbo frames: 9216
Store-and-forward: Yes
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Optical fiber
Transmission distance (max): 60 km
Fiber type: Multi-mode
Fiber ethernet cabling technology: 1000BASE‑SX, 100BASE-FX, 1000BASE‑LX
