Design
Wall mountable: Yes
DIN rail mounting: Yes
International Protection (IP) code: IP30
Housing material: Aluminium
Product colour: Grey, Blue
Reset button: Yes
LED indicators: System, LAN
Power
DC input voltage: 9 - 48 V
Input current: 3.3 A
Security
Queue scheduling algorithms: Weighted Round Robin (WRR)
IGMP snooping: Yes
Access Control List (ACL): Yes
Security algorithms: SSH-2, TLS, SNMPv2, SNMP, SNMPv3
Operational conditions
Operating relative humidity (H-H): 5 - 95%
Operating temperature (T-T): -40 - 75 °C
Storage temperature (T-T): -40 - 85 °C
Management features
Quality of Service (QoS) support: Yes
System event log: Yes
Switch layer: L3
Switch type: Managed
Weight & dimensions
Width: 76.8 mm
Height: 152 mm
Depth: 107.3 mm
Weight: 1.17 kg
Network
Auto-negotiation: Yes
Flow control support: Yes
VLAN support: Yes
Number of VLANs: 256
10G support: No
Auto MDI/MDI-X: Yes
Port mirroring: Yes
Link aggregation: Yes
Spanning tree protocol: Yes
Full duplex: Yes
Virtual LAN features: IP subnet–based VLAN, Voice VLAN, Protocol-based VLAN
Networking standards: IEEE 802.1w, IEEE 802.3ad, IEEE 802.1s, IEEE 802.1ag, IEEE 802.1x, IEEE 802.3u, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1Q, IEEE 802.3x, IEEE 802.1D, IEEE 802.3z
Performance
Internal memory: 512 MB
Flash memory: 64 MB
Memory type: SDRAM
Firmware upgradeable: Yes
Protocols
GARP VLAN Registration Protocol (GVRP): Yes
Routing protocols: OSPF
Ports & interfaces
Console port: RJ-45
Fiber ports quantity: 4
Basic switching RJ-45 Ethernet ports quantity: 16
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Fiber optic connector: SFP
Logistics data
Harmonized System (HS) code: 85176990
Data transmission
Jumbo frames: 10000
Switching capacity: 40 Gbit/s
MAC address table: 16000 entries
Packet buffer memory: 32 MB
Jumbo frames support: Yes
Store-and-forward: Yes
Throughput: 29.76 Mpps
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Multicast features
Multicast support: Yes
