Design
International Protection (IP) code: IP30
Product colour: Blue
Reset button: Yes
Housing material: Metal
Wall mountable: Yes
Form factor: 1U
DIN rail mounting: Yes
LED indicators: Yes
Rack mounting: Yes
Power
Power consumption (max): 10 W
Power consumption (typical): 4.5 W
Security
MAC address filtering: Yes
Security algorithms: SSL/TLS, SSH
SSH/SSL support: Yes
Authentication: Port-based authentication
Loop protection: Yes
IGMP snooping: Yes
BPDU filtering/protection: Yes
Access Control List (ACL): Yes
Operational conditions
Storage relative humidity (H-H): 5 - 95%
Operating temperature (T-T): -40 - 75 °C
Storage temperature (T-T): -40 - 75 °C
Operating relative humidity (H-H): 5 - 95%
Heat dissipation: 15 BTU/h
Management features
Web-based management: Yes
Quality of Service (QoS) support: Yes
Switch layer: L2/L4
Traffic classification: Yes
Switch type: Managed
ARP inspection: Yes
System event log: Yes
Weight & dimensions
Depth: 87 mm
Height: 135 mm
Weight: 472 g
Width: 32 mm
Network
Networking standards: IEEE 802.3ad, IEEE 802.1s, IEEE 802.1x, IEEE 802.1ab, IEEE 802.3u, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3az, IEEE 802.1Q, IEEE 802.3x
Port mirroring: Yes
Number of VLANs: 4094
Flow control support: Yes
10G support: No
Auto MDI/MDI-X: Yes
Virtual LAN features: Private VLAN, Protocol-based VLAN, Stacked VLAN, Tagged VLAN
Rate limiting: Yes
Full duplex: Yes
Copper ethernet cabling technology: 1000BASE-T, 100BASE-TX, 10BASE-T
Spanning tree protocol: Yes
Broadcast storm control: Yes
Link aggregation: Yes
VLAN support: Yes
Half duplex: Yes
Performance
Firmware upgradeable: Yes
Protocols
Supported network protocols: IPv4 / IPv6
Management protocols: Telnet/SNMP
Ports & interfaces
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity: 8
Basic switching RJ-45 Ethernet ports quantity: 8
Other features
Terminal block port: Yes
Logistics data
Harmonized System (HS) code: 85176990
Data transmission
Throughput: 11.9 Mpps
MAC address table: 8000 entries
Switching capacity: 16 Gbit/s
Jumbo frames support: Yes
Jumbo frames: 10000
Store-and-forward: Yes
Number of queues: 8
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Multicast features
Multicast support: Yes
Number of multicast groups filtered: 256
