Design
Product colour: Blue
Wall mountable: Yes
Housing material: Metal
International Protection (IP) code: IP30
Rack mounting: No
DIN rail mounting: Yes
Power
Redundant power supply (RPS) support: Yes
Power consumption (typical): 6.72 W
Operational conditions
Storage temperature (T-T): -40 - 75 °C
Operating relative humidity (H-H): 5 - 95%
Heat dissipation: 23 BTU/h
Storage relative humidity (H-H): 5 - 95%
Operating temperature (T-T): -40 - 75 °C
Management features
Quality of Service (QoS) support: Yes
Switch type: Unmanaged
Switch layer: L2
Weight & dimensions
Depth: 87 mm
Height: 135 mm
Weight: 476 g
Width: 32 mm
Network
Auto-negotiation: Yes
Auto MDI/MDI-X: Yes
Cable types supported: Cat3, Cat5, Cat5e, Cat4, Cat6
Networking standards: IEEE 802.3u, IEEE 802.3, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az
Copper ethernet cabling technology: 1000BASE-T, 10BASE-T, 100BASE-TX
MAC address auto-aging supported: Yes
Full duplex: Yes
10G support: No
MAC address auto-learning supported: Yes
Broadcast storm control: Yes
Flow control support: Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity: 8
Gigabit Ethernet (copper) ports quantity: 8
Other features
Terminal block port: Yes
Logistics data
Harmonized System (HS) code: 85176990
Data transmission
MAC address table: 4000 entries
Throughput: 11.9 Mpps
Store-and-forward: Yes
Jumbo frames: 9000
Switching capacity: 16 Gbit/s
Jumbo frames support: Yes
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
