Certification: FCC, CE
Design
Wall mountable: Yes
International Protection (IP) code: IP30
Rack mounting: No
DIN rail mounting: Yes
Housing material: Metal
Product colour: Blue
Power
Redundant power supply (RPS) support: Yes
Power consumption (typical): 6.72 W
Operational conditions
Operating relative humidity (H-H): 5 - 95%
Storage relative humidity (H-H): 5 - 95%
Heat dissipation: 23 BTU/h
Storage temperature (T-T): -40 - 75 °C
Operating temperature (T-T): -40 - 75 °C
Management features
Switch type: Unmanaged
Quality of Service (QoS) support: Yes
Switch layer: L2
Weight & dimensions
Width: 32 mm
Depth: 87 mm
Height: 135 mm
Weight: 476 g
Network
Cable types supported: Cat4, Cat3, Cat5, Cat5e, Cat6
Broadcast storm control: Yes
MAC address auto-aging supported: Yes
Full duplex: Yes
Copper ethernet cabling technology: 10BASE-T, 1000BASE-T, 100BASE-TX
MAC address auto-learning supported: Yes
Auto-negotiation: Yes
Auto MDI/MDI-X: Yes
10G support: No
Flow control support: Yes
Networking standards: IEEE 802.3x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3az
Ports & interfaces
Gigabit Ethernet (copper) ports quantity: 8
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity: 8
Other features
Terminal block port: Yes
Logistics data
Harmonized System (HS) code: 85176990
Data transmission
Jumbo frames support: Yes
Jumbo frames: 9000
Throughput: 11.9 Mpps
Switching capacity: 16 Gbit/s
Store-and-forward: Yes
MAC address table: 4000 entries
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
