Design Product colour: Blue Housing material: Metal International Protection (IP) code: IP30 LED indicators: Yes Internal: No DIN rail mounting: Yes
Power Power consumption (typical): 3.3 W Input voltage: 12 - 48 V
Operational conditions Operating relative humidity (H-H): 5 - 95% Storage temperature (T-T): -40 - 75 °C Operating temperature (T-T): -40 - 75 °C Storage relative humidity (H-H): 5 - 95%
Weight & dimensions Height: 135 mm Weight: 395 g Depth: 87 mm Width: 32 mm
Network Maximum data transfer rate: 1000 Mbit/s Auto MDI/MDI-X: Yes Ethernet LAN data rates: 10, 1000 Mbit/s, 100 Converter output interface: 1000Base-BX, 1000Base-LX, 1000Base-SX
