Features
Product colour: Blue
Internal: No
International Protection (IP) code: IP30
LED indicators: Power, System
Housing material: Metal
DIN rail mounting: Yes
Power
Input voltage: 9 - 48 V
Input current: 24 A
Operational conditions
Operating relative humidity (H-H): 5 - 90%
Operating temperature (T-T): -40 - 75 °C
Storage relative humidity (H-H): 5 - 90%
Storage temperature (T-T): -40 - 85 °C
Weight & dimensions
Height: 104 mm
Width: 30 mm
Depth: 70 mm
Weight: 221 g
Network
Converter input interface: 1000Base-SX, 10Base-T, 100Base-T, 1000Base-T
Duplex system: Half, Full
Ethernet LAN data rates: 1000 Mbit/s, 10, 100
Converter output interface: 1000Base-LX, 1000Base-BX, 1000Base-SX
Ethernet interface type: Gigabit Ethernet
Networking standards: IEEE 802.3x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3az, IEEE 802.3z
Cable types supported: Cat5, Cat5e, Cat6, Cat3, Cat4
Flow control support: Yes
Maximum data transfer rate: 1000 Mbit/s
Auto MDI/MDI-X: Yes
Auto-negotiation: Yes
Performance
Maximum transfer distance: 100 m
Fiber mode structure: Multi-mode, Single-mode
Ports & interfaces
Fiber ports quantity: 1
Connectivity technology: Wired
Ethernet LAN (RJ-45) ports: 1
Fiber optic connector: SFP
Logistics data
Harmonized System (HS) code: 85176990
