Features
Product colour: Blue
International Protection (IP) code: IP30
Housing material: Metal
DIN rail mounting: Yes
LED indicators: Yes
Power
Total Power over Ethernet (PoE) budget: 30 W
Input voltage: 48 V
Power over Ethernet (PoE): Yes
Operational conditions
Storage relative humidity (H-H): 5 - 90%
Operating relative humidity (H-H): 5 - 90%
Operating temperature (T-T): -40 - 75 °C
Storage temperature (T-T): -40 - 85 °C
Weight & dimensions
Height: 32 mm
Width: 135 mm
Weight: 420 g
Depth: 87 mm
Network
Ethernet LAN data rates: 10, 1000 Mbit/s, 100
Fiber ethernet cabling technology: 1000BASE‑LX
Copper ethernet cabling technology: 1000BASE-SX
Ethernet interface type: Gigabit Ethernet
Networking standards: IEEE 802.3z, IEEE 802.3x, IEEE 802.3at, IEEE 802.3u, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3az
Data transfer rate: 1000 Mbit/s
Auto MDI/MDI-X: Yes
Maximum data transfer rate: 2000 Mbit/s
Auto-negotiation: Yes
Performance
Wavelength: 1310 nm
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Fiber optic connector: SFP
DC-in jack: Yes
Connectivity technology: Wired
Logistics data
Harmonized System (HS) code: 85176990
