Features
Housing material: Metal
Product colour: Blue
International Protection (IP) code: IP30
LED indicators: System, Power, Fault, PoE
DIN rail mounting: Yes
Power
Total Power over Ethernet (PoE) budget: 90 W
Input voltage: 12 - 48 V
Power over Ethernet (PoE): Yes
Operational conditions
Storage temperature (T-T): -40 - 85 °C
Storage relative humidity (H-H): 5 - 90%
Operating temperature (T-T): -40 - 75 °C
Operating relative humidity (H-H): 5 - 90%
Weight & dimensions
Weight: 665 g
Width: 55 mm
Depth: 85 mm
Height: 135 mm
Network
Networking standards: IEEE 802.3ad, IEEE 802.3u, IEEE 802.3at, IEEE 802.3x, IEEE 802.3bt, IEEE 802.3af, IEEE 802.3az, IEEE 802.3z, IEEE 802.3
Flow control support: Yes
Converter output interface: 1000Base-BX, 1000Base-SX, 1000Base-LX
Ethernet LAN data rates: 1000 Mbit/s, 10, 100
Duplex system: Full, Half
Converter input interface: 1000Base-T, 100Base-T, 10Base-T
Ethernet interface type: Gigabit Ethernet
Cable types supported: Cat3, Cat5, Cat5e, Cat4, Cat6
Maximum data transfer rate: 1000 Mbit/s
Performance
Fiber mode structure: Multi-mode, Single-mode
Fiber cable diameters supported (core/cladding): 9/125 µm, 50/125 µm, 62.5/125
Ports & interfaces
Fiber ports quantity: 2
Fiber optic connector: SFP
Connectivity technology: Wired
Power over Ethernet (PoE) ports quantity: 2
Logistics data
Harmonized System (HS) code: 85176990
