Certification: FCC Part 15 Class A, CE
IEC 60068-2-32 (free fall)
IEC 60068-2-27 (shock)
IEC 60068-2-6 (vibration)
Design
Housing material: Metal
LED indicators: Yes
Wall mountable: Yes
International Protection (IP) code: IP30
DIN rail mounting: Yes
Reset button: Yes
Product colour: Blue
Power
Power source: AC/DC
Security
MAC address filtering: Yes
Operational conditions
Operating relative humidity (H-H): 5 - 95%
Storage relative humidity (H-H): 5 - 95%
Operating temperature (T-T): -40 - 75 °C
Storage temperature (T-T): -40 - 85 °C
Management features
Switch type: Managed
ARP inspection: Yes
Cloud-managed: Yes
Quality of Service (QoS) support: Yes
Switch layer: L2/L4
Web-based management: Yes
Weight & dimensions
Depth: 87.8 mm
Width: 32 mm
Height: 135 mm
Weight: 400 g
Network
MAC address auto-aging supported: Yes
Auto MDI/MDI-X: Yes
VLAN support: Yes
MAC address auto-learning supported: Yes
Number of VLANs: 4096
Spanning tree protocol: Yes
Full duplex: Yes
10G support: No
Half duplex: Yes
Networking standards: IEEE 802.3az, IEEE 802.1Q, IEEE 802.3x, IEEE 802.1w, IEEE 802.1D, IEEE 802.3z, IEEE 802.1ad, IEEE 802.3ad, IEEE 802.1s, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1ab, IEEE 802.3u, IEEE 802.1x
Ports & interfaces
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Installed SFP modules quantity: 2
Basic switching RJ-45 Ethernet ports quantity: 4
Data transmission
Store-and-forward: Yes
MAC address table: 8000 entries
Jumbo frames: 9000
Jumbo frames support: Yes
Throughput: 8.9 Mpps
Switching capacity: 12 Gbit/s
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Multicast features
Multicast support: Yes
