Design
DIN rail mounting: Yes
Product colour: Blue
Reset button: Yes
International Protection (IP) code: IP30
Wall mountable: Yes
LED indicators: Yes
Housing material: Metal
Power
Power source: AC/DC
Security
MAC address filtering: Yes
Operational conditions
Operating relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -40 - 85 °C
Storage relative humidity (H-H): 5 - 95%
Operating temperature (T-T): -40 - 75 °C
Management features
ARP inspection: Yes
Cloud-managed: Yes
Quality of Service (QoS) support: Yes
Web-based management: Yes
Switch layer: L2/L4
Switch type: Managed
Weight & dimensions
Height: 135 mm
Depth: 87.8 mm
Width: 32 mm
Weight: 400 g
Network
Full duplex: Yes
Spanning tree protocol: Yes
Auto MDI/MDI-X: Yes
Networking standards: IEEE 802.3u, IEEE 802.3az, IEEE 802.3ad, IEEE 802.1s, IEEE 802.1x, IEEE 802.1Q, IEEE 802.3x, IEEE 802.1ad, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1ab, IEEE 802.1D, IEEE 802.3z, IEEE 802.1w
VLAN support: Yes
Half duplex: Yes
MAC address auto-aging supported: Yes
10G support: No
MAC address auto-learning supported: Yes
Number of VLANs: 4096
Ports & interfaces
Installed SFP modules quantity: 2
Basic switching RJ-45 Ethernet ports quantity: 4
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Data transmission
Store-and-forward: Yes
Throughput: 8.9 Mpps
Jumbo frames support: Yes
Jumbo frames: 9000
Switching capacity: 12 Gbit/s
MAC address table: 8000 entries
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Multicast features
Multicast support: Yes
