Certification: FCC Part 15 Class A,
CE Certification Class A
IEC60068-2-32 (Free fall)
IEC60068-2-27 (Shock)
IEC60068-2-6 (Vibration)
Technical details
Data bits: 5, 6, 8, 7
Stop bits: 1, 2, 1.5
Auto MDI/MDI-X: Yes
Networking standards: IEEE 802.3u, IEEE 802.3
Parity bit: Even, Odd, No, Space, Mark
Serial ports quantity: 2
Flow Control type: DTR/DSR, RTS/CTS, XON/XOFF
Design
Product colour: Blue
International Protection (IP) code: IP30
Housing material: Metal
Operational conditions
Storage relative humidity (H-H): 5 - 95%
Operating relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -40 - 85 °C
Operating temperature (T-T): -40 - 75 °C
Weight & dimensions
Weight: 392 g
Dimensions (WxDxH): 32 x 87.8 x 135 mm
Indication
LED indicators: System
Link/Act LED: Yes
Power LED: Yes
