Design
DIN rail mounting: Yes
Product colour: Blue, Aluminium
International Protection (IP) code: IP30
Wall mountable: Yes
Housing material: Aluminium
LED indicators: Yes
Reset button: Yes
Power
Power source: DC/PoE
Security
SSH/SSL support: Yes
Access Control List (ACL): Yes
IGMP snooping: Yes
Operational conditions
Operating temperature (T-T): -40 - 75 °C
Storage temperature (T-T): -40 - 85 °C
Operating relative humidity (H-H): 5 - 95%
Storage relative humidity (H-H): 5 - 95%
Management features
Traffic classification: Yes
ARP inspection: Yes
System event log: Yes
Cloud-managed: Yes
Quality of Service (QoS) support: Yes
Web-based management: Yes
Switch type: Managed
Switch layer: L2/L4
Weight & dimensions
Width: 76 mm
Height: 152 mm
Depth: 135 mm
Weight: 1.4 kg
Network
Link aggregation: Yes
Spanning tree protocol: Yes
Networking standards: IEEE 802.3af, IEEE 802.3az, IEEE 802.1ab, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3x, IEEE 802.3, IEEE 802.3ad, IEEE 802.1s, IEEE 802.1w, IEEE 802.3at, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1D, IEEE 802.3z, IEEE 802.1x
Auto MDI/MDI-X: Yes
Full duplex: Yes
Half duplex: Yes
VLAN support: Yes
Ports & interfaces
Installed SFP modules quantity: 2
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity: 18
Data transmission
Store-and-forward: Yes
Jumbo frames: 10000
Jumbo frames support: Yes
MAC address table: 8000 entries
Switching capacity: 40 Gbit/s
Throughput: 29.7 Mpps
Power over Ethernet (PoE)
Power over Ethernet (PoE): Yes
