Design
Reset button: Yes
Product colour: Blue, Aluminium
Wall mountable: Yes
International Protection (IP) code: IP30
Housing material: Aluminium
LED indicators: Yes
DIN rail mounting: Yes
Power
Power source: AC/DC
DC input voltage: 9 - 48 V
AC input voltage: 24 V
Security
SSH/SSL support: Yes
IGMP snooping: Yes
Access Control List (ACL): Yes
Operational conditions
Operating temperature (T-T): -40 - 75 °C
Storage temperature (T-T): -40 - 85 °C
Operating relative humidity (H-H): 5 - 95%
Storage relative humidity (H-H): 5 - 95%
Management features
Web-based management: Yes
Quality of Service (QoS) support: Yes
Traffic classification: Yes
ARP inspection: Yes
System event log: Yes
Cloud-managed: Yes
Switch layer: L3
Switch type: Managed
Weight & dimensions
Weight: 1.5 kg
Width: 96 mm
Depth: 107 mm
Height: 152 mm
Network
Networking standards: IEEE 802.3ad, IEEE 802.1s, IEEE 802.1ad, IEEE 802.1x, IEEE 802.1ag, IEEE 802.1ab, IEEE 802.3ah, IEEE 802.3u, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1Q, IEEE 802.3x, IEEE 802.1w, IEEE 802.3az, IEEE 802.1D, IEEE 802.3z, IEEE 802.3ae
Full duplex: Yes
Half duplex: Yes
Auto MDI/MDI-X: Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 16
Installed SFP+ modules quantity: 4
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Data transmission
Jumbo frames: 10000
Store-and-forward: Yes
Throughput: 83.3 Mpps
MAC address table: 32000 entries
Switching capacity: 112 Gbit/s
Jumbo frames support: Yes
