Design
Rack mounting: Yes
Product colour: Blue
LED indicators: Yes
Power
Power source: AC
AC input frequency: 50/60 Hz
AC input voltage: 100 - 240 V
Operational conditions
Storage temperature (T-T): -10 - 70 °C
Operating relative humidity (H-H): 5 - 90%
Storage relative humidity (H-H): 5 - 90%
Operating temperature (T-T): 0 - 50 °C
Management features
Quality of Service (QoS) support: Yes
System event log: Yes
Traffic classification: Yes
Switch layer: L3
Switch type: Managed
Configuring Location Settings (CLI): Yes
Web-based management: Yes
Weight & dimensions
Height: 44 mm
Depth: 207 mm
Width: 440 mm
Weight: 2.74 kg
Network
10G support: Yes
Auto-negotiation: Yes
Full duplex: Yes
Link aggregation: Yes
VLAN support: Yes
MAC address auto-aging supported: Yes
Flow control support: Yes
Spanning tree protocol: Yes
MAC address auto-learning supported: Yes
Half duplex: Yes
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1w, IEEE 802.1ab, IEEE 802.1x, IEEE 802.1ag, IEEE 802.1Q, IEEE 802.3x, IEEE 802.3ad, IEEE 802.1s, IEEE 802.3u, IEEE 802.1D, IEEE 802.3z, IEEE 802.3ae
Ports & interfaces
Fiber optic connector: SFP+
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Installed SFP+ modules quantity: 4
Basic switching RJ-45 Ethernet ports quantity: 24
Data transmission
MAC address table: 32000 entries
Throughput: 95.23 Mpps
Jumbo frames support: Yes
Switching capacity: 128 Gbit/s
Number of IP interfaces: 1024
Jumbo frames: 12000
Power over Ethernet (PoE)
Power over Ethernet (PoE): Yes
