Design DIN rail mounting: Yes Product colour: Black LED indicators: Yes Rack mounting: No Housing material: Metal Wall mountable: Yes International Protection (IP) code: IP30
Power Power consumption (typical): 6 W Input current: 0.5 A
Operational conditions Storage relative humidity (H-H): 5 - 95% Operating relative humidity (H-H): 5 - 95% Operating temperature (T-T): -10 - 60 °C Storage temperature (T-T): -20 - 70 °C Heat dissipation: 20 BTU/h
Management features Switch layer: L2 Switch type: Unmanaged
Weight & dimensions Depth: 24.2 mm Weight: 498 g Height: 134 mm Width: 148 mm
Network Networking standards: IEEE 802.3u, IEEE 802.3x, IEEE 802.3, IEEE 802.3ab Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T Full duplex: Yes 10G support: No MAC address auto-aging supported: Yes MAC address auto-learning supported: Yes Flow control support: Yes
