Features
LED indicators: Link, Power
Housing material: Metal
Internal: No
DIN rail mounting: Yes
Power
Input current: 2 A
Power consumption (typical): 26 W
Input voltage: 5 V
Operational conditions
Storage relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -10 - 70 °C
Operating temperature (T-T): 0 - 50 °C
Operating relative humidity (H-H): 5 - 95%
Weight & dimensions
Depth: 70 mm
Width: 94 mm
Height: 26 mm
Weight: 180 g
Network
Networking standards: IEEE 802.3x, IEEE 802.3u, IEEE 802.3ae, IEEE 802.3bz, IEEE 802.3an, IEEE 802.3ab
Store-and-forward: Yes
Duplex system: Half, Full
Auto-negotiation: Yes
Maximum data transfer rate: 10000 Mbit/s
Auto MDI/MDI-X: Yes
Cable types supported: Cat7, Cat6, Cat5, Cat5e, Cat6a
Ethernet interface type: Fast Ethernet, 5 Gigabit Ethernet, 10 Gigabit Ethernet, 2.5 Gigabit Ethernet, Gigabit Ethernet
Fiber ethernet cabling technology: 10GBASE-X
Flow control support: Yes
Jumbo frames support: Yes
Jumbo frames: 16000
Performance
Fiber cable diameters supported (core/cladding): 62.5/125 µm, 9/125 µm, 50/125
Maximum transfer distance: 60000 m
Fiber mode structure: Multi-mode, Single-mode
Ports & interfaces
Fiber ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
Fiber optic connector: SFP+
Connectivity technology: Wired
Logistics data
Harmonized System (HS) code: 85176990
