Design On/off switch: Yes Cooling type: Active Fan diameter: 12 cm Product colour: White
Power Max output current (+3.3V): 20 A Combined power (+3.3V): 100 W Combined power (+12V): 648 W AC input frequency: 50/60 Hz Combined power (+5Vsb): 15 W Total power: 650 W Input current: 11 - 5.5 A AC input voltage: 100 - 240 V Power protection features: Overheating, Short circuit, Over voltage, Over power, Under voltage, Over current Combined power (-12V): 3.6 W Max output current (+5Vsb): 3 A Max output current (+12V): 54 A Max output current (+5V): 20 A Max output current (-12V): 0.3 A
Operational conditions Operating temperature (T-T): 0 - 50 °C
Weight & dimensions Height: 86 mm Width: 140 mm Depth: 150 mm
Performance Bearing technology: Hypro Bearing ATX version: 3.1 Power supply unit (PSU) form factor: ATX Mean time between failures (MTBF): 100000 h 80 PLUS certification: 80 PLUS Gold Purpose: PC
Ports & interfaces PCI Express power connectors (12+4 pin): 1 PCI Express power connectors (12+4 pin) cable length: 700 mm Cabling type: Fully-Modular PCI Express power connectors (6+2 pin): 1 Peripheral (Molex) power connectors (4-pin): 3 CPU power connector (4+4 pin): Yes Motherboard power connector: 20+4 pin ATX Motherboard power cable length: 61 cm Number of SATA power connectors: 3 SATA power cable length: 750 mm Peripheral (Molex) power cable length: 690 mm CPU power cable length: 75 cm
