Design
Product colour: Black
Cooling type: Active
Number of fans: 1 fan(s)
On/off switch: Yes
Fan diameter: 12 cm
Power
Combined power (+12V): 744 W
Combined power (-12V): 3.6 W
Combined power (+3.3V): 100 W
Max output current (+12V): 62 A
Total power: 750 W
Power protection features: Under voltage, Over current, Over power, Over total voltage, Short circuit, Over voltage
AC input frequency: 50/60 Hz
Max output current (+5Vsb): 3 A
Combined power (+5Vsb): 15 W
AC input voltage: 100 - 240 V
Input current: 9 A
Max output current (+3.3V): 20 A
Max output current (-12V): 0.3 A
Operational conditions
Operating temperature (T-T): 0 - 50 °C
Weight & dimensions
Depth: 140 mm
Height: 86 mm
Width: 150 mm
Performance
Purpose: PC
Power supply unit (PSU) form factor: ATX
ATX version: 3.1
Mean time between failures (MTBF): 100000 h
80 PLUS certification: 80 PLUS Gold
Packaging data
Package type: Box
Packaging content
Cables included: AC, Peripheral (Molex) to SATA 3.3, CPU, PCIe, SATA
Ports & interfaces
Number of PATA power connectors: 2
Cabling type: Fully-Modular
