Design Fan diameter: 12 cm Product colour: Black On/off switch: Yes
Power Max output current (-12V): 0.4 A Combined power (-12V): 4.8 W Maximum input current (@220V): 4.5 A Max output current (+12V1): 45 A Max output current (+5V): 20 A Power Factor Correction (PFC) type: Active Max output current (+3.3V): 20 A Max output current (+5Vsb): 2.5 A Combined power (+5Vsb): 12.5 W AC input voltage: 200 - 240 V Input current: 4.5 A Total power: 600 W Power protection features: Short circuit, Surge protection, Surge and inrush AC input frequency: 50 Hz Power factor: 0.9
Weight & dimensions Width: 150 mm Weight: 1.34 kg Height: 86 mm Depth: 140 mm
Performance ATX version: 2.3 Purpose: PC/Server Power supply unit (PSU) form factor: ATX 80 PLUS certification: 80 PLUS Supported motherboard form factors: ATX
Ports & interfaces CPU power connector (4+4 pin): Yes Motherboard power cable length: 65 cm Peripheral (Molex) power cable length: 750, 600, 450 mm ATX power connector (20+4 pin): Yes SATA power cable length: 750, 600, 450 Number of SATA power connectors: 4 Motherboard power connector: 20+4 pin ATX EPS power connector (4+4 pin): Yes PCI Express power connectors (6+2 pin): 2 Cabling type: Non-Modular
