Design Fan location: Top Product colour: Black Cooling type: Active Fan diameter: 12 cm Number of fans: 1 fan(s)
Power Combined power (+3.3V): 100 W Combined power (-12V): 3.6 W Power Factor Correction (PFC) type: Active Combined power (+5V): 100 W Max output current (+12V): 83.33 A Max output current (+3.3V): 20 A Combined power (+12V): 1000 W Combined power (+5Vsb): 15 W Max output current (+5Vsb): 3 A Max output current (+5V): 20 A Max output current (-12V): 0.3 A Input current: 12-6 A AC input voltage: 100 - 240 V Total power: 1000 W Power protection features: Overheating, Short circuit, Over voltage, Over power, Under voltage, Over current AC input frequency: 50/60 Hz Efficiency: 90%
Weight & dimensions Width: 150 mm Height: 86 mm Depth: 140 mm
Performance EPS version: 2.92 ATX version: 3.1 Bearing technology: HYB 80 PLUS certification: 80 PLUS Gold Power supply unit (PSU) form factor: ATX Purpose: PC
Packaging content Cables included: CPU, Peripheral (Molex), SATA
Ports & interfaces Motherboard power cable length: 60 cm Motherboard power connector: 20+4 pin ATX SATA power cable length: 500 mm CPU power connector (4+4 pin): Yes Number of SATA power connectors: 8 CPU power cable length: 70 cm Cabling type: Fully-Modular Peripheral (Molex) power connectors (4-pin): 4 PCI Express power connectors (6+2 pin): 4
