Design Product colour: Black Fan diameter: 12 cm Number of fans: 1 fan(s) Fan location: Top Cooling type: Active
Power AC input voltage: 110 - 240 V Combined power (+12V): 550 W Total power: 550 W Combined power (+5Vsb): 12.5 W Combined power (+5V): 100 W Max output current (+3.3V): 20 A Power protection features: Overheating, Over power, Short circuit, Over voltage, Under voltage, Over current Combined power (+3.3V): 100 W Max output current (+12V): 45.8 A Max output current (-12V): 0.3 A Max output current (+5Vsb): 2.5 A Efficiency: 90% Power Factor Correction (PFC) type: Active Input current: 8-4 A AC input frequency: 50/60 Hz Max output current (+5V): 20 A Combined power (-12V): 3.6 W
Weight & dimensions Width: 150 mm Depth: 140 mm Height: 86 mm
Performance 80 PLUS certification: 80 PLUS Gold Power supply unit (PSU) form factor: ATX EPS version: 2.92 ATX version: 3.1 Bearing technology: HYB Purpose: PC
Packaging content Cables included: CPU, Peripheral (Molex), SATA
Ports & interfaces Peripheral (Molex) power connectors (4-pin): 4 Motherboard power connector: 20+4 pin ATX Number of SATA power connectors: 8 CPU power connector (4+4 pin): Yes SATA power cable length: 500 mm Cabling type: Non-Modular Motherboard power cable length: 60 cm PCI Express power connectors (6+2 pin): 4 CPU power cable length: 70 cm
