Features Output voltage Total Harmonic Distortion (THD): 5% Input power factor: 0.99 Input frequency: 40 - 70 Hz Output power capacity: 3 kVA Output operation voltage (max): 240 V Output operation voltage (min): 208 V UPS topology: Double-conversion (Online) Crest factor: 3:1 Output power factor: 0.9 Efficiency: 91% Output voltage regulation: ±1% Input operation voltage (min): 80 V Response time: 0 ms Input operation voltage (max): 300 V Output frequency regulation: ±0.5 Hz Waveform: Pure sine Output power: 2700 W
Design Display type: LCD Form factor: Tower Built-in fan: Yes Product colour: Black
Operational conditions Operating relative humidity (H-H): 20 - 90% Operating temperature (T-T): 0 - 40 °C
Weight & dimensions Depth: 416 mm Weight: 25.4 kg Height: 342 mm Width: 196 mm
Packaging data Package height: 458 mm Package weight: 27.1 kg Package width: 294 mm Package depth: 512 mm
Packaging content Cables included: RS-232, USB cable
Ports & interfaces USB port type: USB Type-B AC outlets quantity: 4 AC outlet(s) USB port: Yes AC outlet types: Type E RS-232 ports: 1 Power plug: C20 coupler USB 2.0 ports quantity: 1
Battery Battery recharge time: 4 h Number of batteries supported: 6 Battery voltage: 12 V Battery capacity: 9 Ah Typical backup time at half load: 11 min Typical backup time at full load: 3.5 min
Logistics data Harmonized System (HS) code: 85078000
Safety warning Warnings: Do not disassemble the unit housing, there may be a risk of electric shock., Use the appliance in well-ventilated areas to avoid overheating., Keep away from sources of fire and water.
