Design Fan location: Top Cooling type: Active Product colour: Black On/off switch: Yes Fan diameter: 12 cm Number of fans: 1 fan(s)
Power Total power: 850 W Max output current (+12V): 70.8 A Combined power (+3.3V): 100 W Max output current (+3.3V): 20 A Power Factor Correction (PFC) type: Active AC input frequency: 50 Hz Power protection features: Under voltage, Over power, Short circuit, Over voltage Max output current (+5V): 20 A AC input voltage: 200 - 240 V Input current: 10 A Combined power (+12V): 850 W Max output current (-12V): 0.3 A Max output current (+5Vsb): 3 A
Performance Power supply unit (PSU) form factor: ATX 80 PLUS certification: 80 PLUS Bronze Purpose: PC Bearing technology: FDB ATX version: 2.4
Packaging data Package weight: 1.98 kg Package type: Box
Certificates Compliance certificates: WEEE, RoHS
Ports & interfaces Peripheral (Molex) power connectors (4-pin): 3 PCI Express power connectors (6+2 pin): 4 Cabling type: Non-Modular Motherboard power cable length: 50 cm Motherboard power connector: 20+4 pin ATX ATX power connector (20+4 pin): Yes CPU power connector (4+4 pin): Yes Number of SATA power connectors: 8 PCI Express connector: Yes
