Features Output power capacity: 3 kVA ECO mode: Yes Response time: 6 ms Power source type: AC Output power factor: 0.6 Output power: 1800 W UPS topology: Line-Interactive Noise level: 45 dB Input frequency: 50/60 Hz Output voltage regulation: 10% Detachable power cord: Yes Input operation voltage (min): 162 V Waveform: Pseudo sine Automatic Voltage Regulation (AVR): Yes Input operation voltage (max): 290 V Efficiency (On-line mode): 93%
Design Cooling type: Active Form factor: Tower Display type: LCD Control type: Buttons International Protection (IP) code: IP20 Product colour: Black LED indicators: Yes Built-in fan: Yes
Operational conditions Operating temperature (T-T): 0 - 40 °C Operating relative humidity (H-H): 0 - 90%
Weight & dimensions Weight: 18.1 kg Width: 151 mm Depth: 394 mm Height: 225 mm Bundled software: PowerMaster
Packaging data Package width: 241 mm Package depth: 512 mm Package height: 313 mm Package weight: 19.5 kg
Certificates Compliance certificates: CE
Ports & interfaces AC outlets quantity: 6 AC outlet(s) USB port type: USB Type-B AC outlet types: C13 coupler Ethernet LAN (RJ-45) ports: 1 USB port: Yes Modem (RJ-11) ports: 1 Power plug: C20 coupler
Battery Battery voltage: 12 V Cold start: Yes Battery recharge time: 8 h Typical backup time at full load: 1 min Battery capacity: 7 Ah Number of batteries supported: 4 Typical backup time at half load: 3.5 min Charging current: 0.7 A
