Features Output power capacity: 3 kVA Output power: 1800 W Input frequency: 50/60 Hz Output power factor: 0.6 Power source type: AC Noise level: 45 dB ECO mode: Yes Response time: 6 ms Input operation voltage (min): 162 V Input operation voltage (max): 290 V Detachable power cord: Yes Automatic Voltage Regulation (AVR): Yes Waveform: Pseudo sine UPS topology: Line-Interactive Efficiency (On-line mode): 93% Output voltage regulation: 10%
Design Display type: LCD Control type: Buttons Form factor: Tower Cooling type: Active Product colour: Black International Protection (IP) code: IP20 LED indicators: Yes Built-in fan: Yes
Operational conditions Operating relative humidity (H-H): 0 - 90% Operating temperature (T-T): 0 - 40 °C
Weight & dimensions Depth: 394 mm Weight: 18.1 kg Width: 151 mm Height: 225 mm Bundled software: PowerMaster
Packaging data Package depth: 512 mm Package width: 241 mm Package height: 313 mm Package weight: 19.5 kg
Certificates Compliance certificates: CE
Ports & interfaces Ethernet LAN (RJ-45) ports: 1 AC outlet types: Type F USB port: Yes Modem (RJ-11) ports: 1 AC outlets quantity: 4 AC outlet(s) Power plug: C20 coupler USB port type: USB Type-B Number of type F outputs: 4
Battery Battery recharge time: 8 h Typical backup time at half load: 3.5 min Cold start: Yes Battery capacity: 7 Ah Number of batteries supported: 4 Battery voltage: 12 V Typical backup time at full load: 1 min Charging current: 0.7 A
