Features Emergency Power Off (EPO): Yes Output power: 1000 W UPS topology: Double-conversion (Online) Input current Total Harmonic Distortion (THD): 1.6% Crest factor: 3:1 Surge protection features: Network, Modem, Fax Output operation voltage (max): 240 V Power factor: 0.99 Input frequency: 40/70 Hz Output voltage regulation: 1% Efficiency: 89% Input operation voltage (min): 110 V Output operation voltage (min): 200 V Input operation voltage (max): 300 V Output voltage Total Harmonic Distortion (THD): 2% Surge protection: Yes Noise level: 50 dB Output power capacity: 1 kVA
Design Product colour: Black Form factor: Tower Cooling type: Active Display type: LCD
Operational conditions Operating relative humidity (H-H): 20 - 95% Operating temperature (T-T): 0 - 40 °C
Weight & dimensions Depth: 397 mm Height: 221 mm Width: 145 mm Weight: 13 kg Bundled software: ViewPower
Packaging data Package depth: 472 mm Package weight: 15 kg Package type: Box Package width: 230 mm Package height: 325 mm Warranty card: Yes Resource CD: Yes
Packaging content Cables included: Input power cable, Output power cable, USB cable Manual: Yes
Ports & interfaces AC outlet types: C13 coupler Serial interface type: RS-232 Serial interface: Yes AC outlets quantity: 4 AC outlet(s) Power plug: C14 coupler USB port: Yes Emergency Power Off (EPO) connector: Yes
Battery Battery voltage: 12 V Typical backup time at full load: 4.5 min Battery capacity: 7 Ah Typical backup time at half load: 12.9 min Number of batteries supported: 3 Battery recharge time: 3 h
Logistics data Harmonized System (HS) code: 85078000
