Features Noise level: 45 dB Input frequency: 40/70 Hz Output operation voltage (min): 200 V Response time: 0 ms Waveform: Pure sine Output voltage Total Harmonic Distortion (THD): 1% Output operation voltage (max): 240 V Input current Total Harmonic Distortion (THD): 5% ECO mode: Yes Output power factor: 1 Emergency Power Off (EPO): Yes UPS topology: Double-conversion (Online) Power protection features: Overload Crest factor: 3:1 Output voltage regulation: 1% Output power: 1000 W Input power factor: 0.99 Output power capacity: 1 kVA Input operation voltage (max): 300 V Input operation voltage (min): 160 V Efficiency (On-line mode): 89%
Design Cooling type: Active Built-in fan: Yes Rack capacity: 2U Display type: LCD Product colour: Black Form factor: Rackmount/Tower LED indicators: Yes
Operational conditions Operating relative humidity (H-H): 0 - 95% Operating temperature (T-T): 0 - 45 °C
Weight & dimensions Width: 438 mm Weight: 14.3 kg Height: 85.5 mm Depth: 445 mm
Packaging data Package weight: 17.3 kg Package width: 498 mm Package height: 240 mm Package depth: 587 mm
Packaging content Cables included: Input power cable, Output power cable, USB cable Rack mount kit: Yes Manual: Yes
Ports & interfaces Serial interface: Yes Emergency Power Off (EPO) connector: Yes AC outlet types: C13 coupler USB port: Yes Serial ports quantity: 1 Serial interface type: RS-232 AC outlets quantity: 8 AC outlet(s) Power plug: C14 coupler
Battery Charging current: 1.5 A Battery capacity: 7 Ah Number of batteries supported: 3 Battery voltage: 12 V Battery recharge time: 3 h
Logistics data Harmonized System (HS) code: 85078000
