Features Output operation voltage (max): 240 V Power factor: 0.99 Output power capacity: 1 kVA Input current Total Harmonic Distortion (THD): 1.6% Output voltage Total Harmonic Distortion (THD): 2% Noise level: 50 dB Output operation voltage (min): 200 V Surge protection features: Fax, Network, Modem Surge protection: Yes Input operation voltage (min): 110 V Crest factor: 3:1 Input operation voltage (max): 300 V Input frequency: 40/70 Hz Output power: 1000 W Emergency Power Off (EPO): Yes Output voltage regulation: 1% UPS topology: Double-conversion (Online) Waveform: Sine
Design Display type: LCD Form factor: Rackmount Rack capacity: 2U Product colour: Black
Operational conditions Operating relative humidity (H-H): 20 - 95% Operating temperature (T-T): 0 - 40 °C
Weight & dimensions Height: 88 mm Width: 438 mm Depth: 410 mm Weight: 14.1 kg Bundled software: ViewPower / ViewPowerMini
Packaging data Resource CD: Yes Package weight: 17.6 kg Warranty card: Yes Package width: 500 mm Package type: Box Package height: 180 mm Package depth: 560 mm
Packaging content Cables included: Input power cable, Output power cable, USB cable Manual: Yes
Ports & interfaces Serial interface type: RS-232 Modem (RJ-11) ports: 1 Power plug: C14 coupler USB port: Yes AC outlet types: C13 coupler RS-232 ports: 1 Ethernet LAN (RJ-45) ports: 1 USB 2.0 ports quantity: 1 Number of type F outputs: 8 Emergency Power Off (EPO) connector: Yes Serial interface: Yes
Battery Battery recharge time: 3 h Typical backup time at half load: 12.9 min Typical backup time at full load: 4.5 min Battery capacity: 7 Ah Number of batteries supported: 3 Battery voltage: 12 V
Logistics data Harmonized System (HS) code: 85078000
