Features UPS topology: Double-conversion (Online) Power factor: 0.9 Output voltage regulation: 2% Output power capacity: 1 kVA Waveform: Sine Output voltage Total Harmonic Distortion (THD): 5% Noise level: 45 dB Efficiency: 89% Crest factor: 3:1 Input current Total Harmonic Distortion (THD): 5% Input operation voltage (min): 176 V Input operation voltage (max): 300 V Output power: 900 W Output operation voltage (min): 220 V Emergency Power Off (EPO): Yes Input frequency: 40 - 70 Hz Output operation voltage (max): 240 V
Design Product colour: Black
Operational conditions Operating temperature (T-T): 0 - 40 °C Operating relative humidity (H-H): 0 - 95%
Weight & dimensions Depth: 356 mm Weight: 9.3 kg Width: 144 mm Height: 229 mm
Packaging data Package depth: 436 mm Package width: 240 mm Package height: 330 mm Software CD: Yes Package weight: 11 kg
Packaging content Cables included: Input power cable, USB cable Manual: Yes
Ports & interfaces Emergency Power Off (EPO) connector: Yes AC outlet types: C13 coupler RS-232 ports: 1 USB port: Yes Power plug: C14 coupler AC outlets quantity: 4 AC outlet(s)
Battery Typical backup time at full load: 3.7 min Battery capacity: 9 Ah Number of batteries supported: 2 Battery voltage: 12 V Typical backup time at half load: 10.5 min Battery recharge time: 4 h
Logistics data Harmonized System (HS) code: 85078000
