Features Input current Total Harmonic Distortion (THD): 5% Output voltage regulation: 1% UPS topology: Double-conversion (Online) Efficiency: 89% ECO mode: Yes Crest factor: 3:1 Output power factor: 1 Output operation voltage (min): 200 V Waveform: Sine Output voltage Total Harmonic Distortion (THD): 1% Output operation voltage (max): 240 V Emergency Power Off (EPO): Yes Input operation voltage (min): 110 V Response time: 0 ms Input operation voltage (max): 300 V Output power: 1500 W Output power capacity: 1.5 kVA Input frequency: 40/70 Hz Noise level: 45 dB
Design LED indicators: Yes Form factor: Rackmount/Tower Display type: LCD
Operational conditions Operating relative humidity (H-H): 0 - 95% Operating temperature (T-T): 0 - 45 °C
Weight & dimensions Height: 85.5 mm Width: 438 mm Weight: 15.8 kg Depth: 445 mm
Packaging data Package depth: 587 mm Package height: 240 mm Package weight: 19 kg Package width: 498 mm
Packaging content Cables included: Input power cable, Output power cable, USB cable Manual: Yes
Ports & interfaces Emergency Power Off (EPO) connector: Yes AC outlet types: C13 coupler Serial interface: Yes Serial interface type: RS-232 AC outlets quantity: 8 AC outlet(s) USB 2.0 ports quantity: 1 Power plug: C14 coupler USB port: Yes Serial ports quantity: 1
Battery Hot-swap battery: Yes Charging current: 1.5 A Battery capacity: 9 Ah Number of batteries supported: 3 Battery voltage: 12 V Battery recharge time: 3 h
Logistics data Harmonized System (HS) code: 85078000
Safety warning Warnings: Keep away from sources of fire and water., Use the appliance in well-ventilated areas to avoid overheating., Do not disassemble the unit housing, there may be a risk of electric shock.
