Features Input current Total Harmonic Distortion (THD): 5% Output operation voltage (min): 200 V Crest factor: 3:1 Power protection features: Overload Output voltage Total Harmonic Distortion (THD): 1% Waveform: Pure sine Input power factor: 0.99 Input frequency: 40/70 Hz Noise level: 45 dB Output power factor: 1 ECO mode: Yes Response time: 0 ms Output power capacity: 1.5 kVA Output voltage regulation: 1% UPS topology: Double-conversion (Online) Output operation voltage (max): 240 V Number of input phases: 1 Number of output phases: 1 Efficiency (On-line mode): 89% Input operation voltage (min): 160 V Input operation voltage (max): 300 V Emergency Power Off (EPO): Yes Output power: 1500 W
Design Display type: LCD Built-in fan: Yes Cooling type: Active Form factor: Tower LED indicators: Yes Product colour: Black
Operational conditions Operating relative humidity (H-H): 0 - 95% Operating temperature (T-T): 0 - 45 °C
Weight & dimensions Height: 220 mm Weight: 14.3 kg Depth: 404 mm Width: 145 mm
Packaging data Package weight: 15.7 kg Package width: 495 mm Package height: 339 mm Package depth: 240 mm
Ports & interfaces Serial interface type: RS-232 Serial interface: Yes AC outlets quantity: 4 AC outlet(s) Emergency Power Off (EPO) connector: Yes AC outlet types: C13 coupler Serial ports quantity: 1 USB port: Yes Power plug: C14 coupler
Battery Charging current: 1.5 A Battery voltage: 12 V Number of batteries supported: 3 Battery capacity: 9 Ah Battery recharge time: 3 h
Logistics data Harmonized System (HS) code: 85078000
Safety warning Warnings: Do not disassemble the unit housing, there may be a risk of electric shock., Keep away from sources of fire and water., Use the appliance in well-ventilated areas to avoid overheating.
