Features Surge protection features: Modem, Network, Fax Waveform: Sine Output power: 1500 W Output operation voltage (min): 200 V UPS topology: Double-conversion (Online) Noise level: 50 dB Output voltage regulation: 1% Output power capacity: 1.5 kVA Power factor: 0.99 Emergency Power Off (EPO): Yes Input current Total Harmonic Distortion (THD): 1.6% Crest factor: 3:1 Input operation voltage (max): 300 V Surge protection: Yes Input frequency: 40/70 Hz Output voltage Total Harmonic Distortion (THD): 2% Input operation voltage (min): 110 V Output operation voltage (max): 240 V
Design Form factor: Rackmount Product colour: Black Display type: LCD Rack capacity: 2U
Operational conditions Operating relative humidity (H-H): 20 - 95% Operating temperature (T-T): 0 - 40 °C
Weight & dimensions Depth: 410 mm Width: 438 mm Height: 88 mm Weight: 15.5 kg Bundled software: ViewPower / ViewPowerMini
Packaging data Package depth: 560 mm Warranty card: Yes Package type: Box Package height: 180 mm Package width: 500 mm Package weight: 19 kg Resource CD: Yes
Packaging content Cables included: Input power cable, Output power cable, USB cable Manual: Yes
Ports & interfaces Serial interface: Yes RS-232 ports: 1 AC outlet types: C13 coupler USB 2.0 ports quantity: 1 Number of type F outputs: 8 Power plug: C14 coupler Serial interface type: RS-232 USB port: Yes Modem (RJ-11) ports: 1 Emergency Power Off (EPO) connector: Yes Ethernet LAN (RJ-45) ports: 1
Battery Battery voltage: 12 V Number of batteries supported: 3 Battery capacity: 9 Ah Typical backup time at full load: 3 min Typical backup time at half load: 10.3 min Battery recharge time: 3 h
Logistics data Harmonized System (HS) code: 85078000
