Features Output frequency regulation: -0.5 - 0.5 Hz Output voltage regulation: -1 - 1% Automatic Voltage Regulation (AVR): Yes UPS topology: Double-conversion (Online) Emergency Power Off (EPO): Yes Output voltage Total Harmonic Distortion (THD): 5% Surge protection: Yes Output power capacity: 3 kVA Output operation voltage (min): 208 V Output power: 2700 W Output power factor: 0.9 Input frequency: 40/70 Hz Crest factor: 3:1 Input power factor: 0.99 Waveform: Pure sine Output operation voltage (max): 240 V Input operation voltage (max): 300 V Input operation voltage (min): 80 V
Design Display type: LCD Product colour: Black Form factor: Tower Built-in fan: Yes
Operational conditions Operating relative humidity (H-H): 20 - 90% Operating temperature (T-T): 0 - 40 °C
Weight & dimensions Weight: 21 kg Depth: 416 mm Width: 196 mm Height: 342 mm
Packaging data Package height: 458 mm Package depth: 512 mm Package width: 294 mm Package weight: 27.7 kg
Ports & interfaces USB port type: USB Type-B AC outlet types: Type F, Terminal USB port: Yes AC outlets quantity: 4 AC outlet(s) RS-232 ports: 1 Power plug: C20 coupler USB 2.0 ports quantity: 1
Battery Battery voltage: 12 V Battery capacity: 9 Ah Number of batteries supported: 6
Logistics data Harmonized System (HS) code: 85078000
