Technical details Harmonized System (HS) code: 85078000
Features UPS topology: Double-conversion (Online) Power factor: 0.99 Output power capacity: 3 kVA Output voltage regulation: 1% Surge protection features: Modem, Network, Fax Emergency Power Off (EPO): Yes Input current Total Harmonic Distortion (THD): 1.6% Surge protection: Yes Efficiency: 89% Output power: 3000 W Output voltage Total Harmonic Distortion (THD): 2% Input operation voltage (max): 300 V Output operation voltage (min): 200 V Output operation voltage (max): 240 V Input operation voltage (min): 110 V Noise level: 50 dB Input frequency: 40/70 Hz Crest factor: 3:1
Design Product colour: Black Display type: LCD Form factor: Tower Cooling type: Active
Operational conditions Operating relative humidity (H-H): 20 - 95% Operating temperature (T-T): 0 - 40 °C
Weight & dimensions Depth: 421 mm Weight: 28 kg Height: 318 mm Package width: 230 mm Width: 190 mm Package type: Box Package height: 325 mm Bundled software: ViewPower
Packaging data Manual: Yes Cables included: Input power cable, Output power cable, USB cable Resource CD: Yes Warranty card: Yes
Ports & interfaces Serial interface type: RS-232 AC outlet types: C19 coupler, C13 coupler USB port: Yes Serial interface: Yes Emergency Power Off (EPO) connector: Yes AC outlets quantity: 9 AC outlet(s) Power plug: C20 coupler
Battery Typical backup time at full load: 3 min Battery voltage: 12 V Battery recharge time: 6 h Typical backup time at half load: 10.1 min Battery capacity: 9 Ah Number of batteries supported: 3
