Features Waveform: Pure sine Emergency Power Off (EPO): Yes Input current Total Harmonic Distortion (THD): 5% Input power factor: 0.99 Power protection features: Overload Input frequency: 40/70 Hz ECO mode: Yes Output power: 3000 W Crest factor: 3:1 Response time: 0 ms UPS topology: Double-conversion (Online) Output operation voltage (min): 200 V Output operation voltage (max): 240 V Output power capacity: 3 kVA Output voltage regulation: 1% Noise level: 50 dB Output power factor: 1 Input operation voltage (min): 160 V Input operation voltage (max): 300 V Output voltage Total Harmonic Distortion (THD): 1%
Design Display type: LCD Cooling type: Active Form factor: Tower Product colour: Black Built-in fan: Yes LED indicators: Yes
Operational conditions Operating temperature (T-T): 0 - 45 °C Operating relative humidity (H-H): 0 - 95%
Weight & dimensions Height: 318 mm Width: 192 mm Depth: 428 mm Weight: 26.4 kg
Packaging data Package height: 475 mm Package width: 590 mm
Packaging content Manual: Yes Cables included: Input power cable, Output power cable, USB cable
Ports & interfaces Serial interface type: RS-232 Serial ports quantity: 1 Serial interface: Yes AC outlets quantity: 9 AC outlet(s) Emergency Power Off (EPO) connector: Yes USB port: Yes AC outlet types: C13 coupler, C19 coupler Power plug: C20 coupler
Battery Battery capacity: 9 Ah Battery voltage: 12 V Charging current: 1.5 A Battery recharge time: 3 h Number of batteries supported: 6
Logistics data Harmonized System (HS) code: 85078000
Safety warning Warnings: Do not disassemble the unit housing, there may be a risk of electric shock.
