Features Input current Total Harmonic Distortion (THD): 1.6% Crest factor: 3:1 Surge protection features: Modem, Network, Fax Waveform: Sine Output operation voltage (min): 200 V Output voltage Total Harmonic Distortion (THD): 2% Output power: 3000 W Power factor: 0.99 UPS topology: Double-conversion (Online) Output power capacity: 3 kVA Output voltage regulation: 1% Surge protection: Yes Input operation voltage (min): 110 V Input operation voltage (max): 300 V Noise level: 50 dB Input frequency: 40/70 Hz Emergency Power Off (EPO): Yes Output operation voltage (max): 240 V
Design Product colour: Black Display type: LCD Form factor: Rackmount/Tower
Operational conditions Operating temperature (T-T): 0 - 40 °C Operating relative humidity (H-H): 20 - 95%
Weight & dimensions Height: 318 mm Weight: 27.5 kg Width: 190 mm Depth: 630 mm Bundled software: ViewPower / ViewPowerMini
Packaging data Package height: 200 mm Package width: 600 mm Package type: Box Resource CD: Yes Warranty card: Yes
Packaging content Manual: Yes Cables included: Input power cable, Output power cable, USB cable
Ports & interfaces Emergency Power Off (EPO) connector: Yes Serial interface: Yes RS-232 ports: 1 Number of type F outputs: 9 Serial interface type: RS-232 Ethernet LAN (RJ-45) ports: 1 AC outlet types: C13 coupler, C19 coupler USB port: Yes Modem (RJ-11) ports: 1 Power plug: C14 coupler USB 2.0 ports quantity: 1
Battery Number of batteries supported: 6 Battery voltage: 12 V Battery capacity: 9 Ah Typical backup time at full load: 3 min Typical backup time at half load: 10.1 min Battery recharge time: 3 h
Logistics data Harmonized System (HS) code: 85078000
Safety warning Warnings: Do not disassemble the unit housing, there may be a risk of electric shock.
