Features Output voltage regulation: -2 - 2% Input power factor: 0.99 Noise level: 50 dB Output operation voltage (min): 220 V Crest factor: 3:1 Output power factor: 0.9 Input frequency: 40 - 70 Hz Output power: 2700 W Emergency Power Off (EPO): Yes Efficiency: 90% UPS topology: Double-conversion (Online) Output power capacity: 3 kVA Output operation voltage (max): 240 V Output frequency regulation: -0.05 - 0.05 Hz Response time: 4 ms Input operation voltage (min): 80 V Input operation voltage (max): 300 V
Design Form factor: Tower Product colour: Black Display type: LCD Cooling type: Active LED indicators: Yes
Operational conditions Operating relative humidity (H-H): 0 - 95% Operating temperature (T-T): 0 - 40 °C
Weight & dimensions Package height: 324 mm Depth: 399 mm Height: 328 mm Width: 190 mm Weight: 22.2 kg Package width: 500 mm
Packaging data Cables included: Input power cable, USB cable Resource CD: Yes Manual: Yes
Ports & interfaces Emergency Power Off (EPO) connector: Yes AC outlet types: C13 coupler, C19 coupler RS-232 ports: 1 AC outlets quantity: 5 AC outlet(s) Power plug: C20 coupler USB 2.0 ports quantity: 1
Battery Typical backup time at full load: 4.5 min Number of batteries supported: 6 Battery capacity: 9 Ah Battery recharge time: 4 h Charging current: 1.5 A Battery voltage: 12 V
Logistics data Harmonized System (HS) code: 85078000
